Auto Lensmeter with Printer - 7'' New Touch Screen - PD, PH, UV, Lens diameter, PCL - RS232 serial port, Bluetooth, USB, WIFI

Auto Lensmeter

This type auto lensometer with capacitive touch screen, high resolution, can be measured PD, PH, UV, Lens Diameter, PCL and so on, it also has printing function. FDA and CE Certification and one year warranty.

Product Features

Simple Graphical UI
Built-in thermal printer
Hartmann Sensors
Auto memory and screensaver
Function: It can measure SPH, CYL, AXIS, ADD, Prism Power, PD, PH, UV, Lens Diameter and PCL (Progressive Channel Length). And the wavelength of UV and green light can be measured simultaneously.
Types of measurable lenses: single vision lenses, bifocal/trifocal lenses, progressive lens and contact lens (can automatically recognize single and progressive lens)
7" TFT LCD screen: It can be tilted, 40-90 ° adjustable, and the new capacitive touch panel has high resolution.
The form of data communication: RS232 serial port, Bluetooth, USB and WIFI.
Superior quality: Better performance, finer marking pens and lens holder, magnetic and stable sliding nose piece.
Certification and warranty: FDA, CE certification and one year warranty

JD-2600D vs. JD-2600A vs. D-910

JD-2600A is an auto lensometer with good comprehensive performance, which can measure SPH, CYL, AXIS, ADD, Prism, PD, PH, UV. Its data communication form is RS232 serial port.

Although the configuration of JD-2600D is slightly lower than JD-2600A, as a basic model, it can basically meet daily measurement needs. Apart from minor differences in appearance, screen quality, and machine material, the JD-2600D does not provide a Pupil Height (PH) measurement compared to the JD-2600A in terms of functionality.

D-910 is a fully upgraded version of JD-2600A. The basic measurement function and measurable lens types of JD-2600A are supported by the D-910. At the same time, the D-910 has better performance, better display screen, higher measurement accuracy, and more optional data communication methods.

Screen quality and machine material: JD-2600D<JD-2600A<D-910

SKU	Display	Measurement	Data communication
JD-2600D	7" 20-85°adjustable LCD touch display screen	SPH, CYL, AXIS, ADD, Prism, PD, UV	RS232 serial port
JD-2600A	7" 20-85°adjustable LCD touch display screen	SPH, CYL, AXIS, ADD, Prism, PD, UV, PH	RS232 serial port
D-910	7" 40-90°adjustable New capacitive touch screen with high resolution	SPH, CYL, AXIS, ADD, Prism, PD, UV, PH, Lens Diameter and PCL	RS232 serial port Bluetooth USB WIFI

You can choose according to your needs.

Specification

Model	D-910
Measurement Range
Sphere	0 ～ ±25 D，0.01/0.12/0.25 D step
Cylinder	0 ～ ±9.99 D，0.01/0.12/0.25 D step
Axis	0 ～ 180° (1° step)
Add.	0 ～ +9.99 D，0.01/0.12/0.25 D step
Prism degree	0 ～ 15 D，0.01/0.12/0.25 D step
Measurement Mode
Cylinder	+, -, ±
Prism	X_Y, P-B
Contact lens	soft/hard lens
Measuring mode	single lens/progressive lens/contact lens (automatic recognition)
Specifications
Diameter of lens	Φ12 ～ Φ112 mm
PD	40 ～ 90 mm, 0.5 mm steps
Speed of measurement	0.1 s
Light source	LED Green Source
ABBE Value	30 ～ 60, no need to set
Display	7" TFT LCD Tilting Touch Screen new capacitive touch screen with high resolution
UV	Y
Printer	Thermal Printer
Data communication	RS232 serial port,Bluetooth, USB and WIFI
Dimension	180 x 255 x 455 mm
Package	620 x 390 x 390 mm
Weight	12kg
Power supply	AC 100 ～ 240 V, 50/60 Hz
